TEK Power Control Panels

We engaged in supplying and manufacturing a wide range of Control Panel. These panels are made using quality raw materials as these high performing control panels are used widely over in many industrial and other applications. The flawless design and superior framing of these panels have made it the first choice of the customers.

Power Control Center (PCC) Panels

Owing to our expertise in this domain, we are engaged in offering a supreme quality PCC Panel that is used to supervise and control the voltage of power systems. Power Control Center panels for various industrial applications to provide reliable and effective distribution service. They are used to supervise and control the voltage and reactive power of the power system.

The panels will undergo pretreatment for Decreasing, Water rinsing & De-rusting/ Phosphating, It will be painted with Powder Coated or Synthetic enamel as per the requirements. Bus Bars / Internal Wiring uniform cross section and supported by SMC /DMC bases. Earthing Bus Bars will be running all along the Panel. Some of the Applications of PCCs are Dairy, Plastic industry, Refrigeration plants.

Motor Control Center (MCC) Panel

We design & manufacture low voltage switchgear panels & motor control center. Our in house design & good engineering practices in manufacturing combined together forms the ideal solution to the most demanding motor control applications throughout the industrial market.

A motor controller is a device or group of devices that serves to govern in some predetermined manner the performance of an electric motor. A motor controller might include a manual or automatic means for starting and stopping the motor, selecting forward or reverse rotation, selecting and regulating the speed, regulating or limiting the torque, and protecting against overloads and faults. Every electric motor has a controller. The motor controller will have differing features and complexity depending on the task that the motor will be performing on.

  • CNC construction
  • Safe and reliable operation
  • Certified panels from IP42 to IP65
  • Components from Tier – 1 vendors
  • Labelled and colour coded wiring
  • 3D-CAD (Solid works & Auto CAD)
  • Easy operation
  • Controlling heavy starting currents.

Lighting Panels

It allow the most cost effective ratings for the particular application. Two and three-pole breakers may be fitted with a range of internal accessories (shunt trip, undervoltage release, auxiliary switch, bell alarm). When fitted to the three-pole mounting base, the TEY family circuit breakers can be used in unit mount/lug-lug type installations.

Auto Power Factor Correction (APFC) Panels

Designed with the concept of modularity which allows upgrading of kVAR rating as and when required. Advanced microprocessor based relay used to ensure real time power factor correction in the installation. Current limiting contractors are used which are specially designed for capacitor switch.

They are used to Supervise and Control the voltage and reactive power of the power system. We manufacture and supply a qualitative range of APFC panels, that are extensively used in various industries. These automatic power factor control panel (APFC) are designed and developed using advanced techniques and are capable of saving maximum power and energy. These APFC Panel are highly efficient and accurately monitor the reactive power in power systems for saving energy and can alter the system voltage as well as current.

  • Modular to upgrade, up to 500 KVAR
  • Capacitors : L&T, ABB, Epcos
  • PF controllers : Epcos , L&T, Schneider
  • Thyristorised or contactor based
  • Designed with the concept of modularity
  • Easiness in operation, very low manual intervention
  • Avoid power factor penalty

Programmable Logic Controller (PLC) Panels

We are a reckoned organization engaged in manufacturing and supplying a comprehensive range of PLC Panels. These panels are highly appreciated for their longer functional life, easy installation and low maintenance.

Our professionals make optimum utilization of the resources and develop excellent quality range of panels for the clients. Our professionals make sure to deliver effective range of panels at nominal prices to the clients.

  • SS / MS / FRP / FLP Panels
  • Integrated with PLC, HMI, Barriers, VFD etc
  • HMI’s with screen size 3.5″ to 22″
  • Desk type / Floor standing / Wall mount
  • Customised as per requirement
  • PLC’s from Siemens/ AB / FUJI / Mitsubishi / ABB / Schneider / Delta, etc

Variable Frequency Drive (VFD) Panels

VFD Panels are designed to control the speed and torque of electric motors by varying input frequency and voltage to motors. VFD Panels are used as energy saving devices as they adjust motor speed under no load conditions or as required by the process.

Such energy cost savings are especially pronounced in variable torque centrifugal fan and pump applications where there is large power reduction for a relatively small reduction in speed. We design and manufacture a diverse range of VFD panels for varied applications (closed-loop and open-loop applications).

  • AHU / Chiller control
  • Pump / Motor / Blower speed control
  • Reactor control
  • Conveyor / Crane system
  • Remote / Local / Bypass control options
  • 1-400 HP (0.7457 KW- 298.28 KW) drive panel
  • Siemens /AB / Danfoss / Mitsubishi / ABB Naskawa / Delta

Energy Monitoring System

Our offered Energy Monitoring System is manufactured by utilizing optimum quality raw materials and advanced technology by our vendors’ skilled professionals. In order to ensure quality, the entire range is rigorously tested on various parameters. In tune with international standards, we provide the entire range in various specifications, as per the requirements of our clients.

Energy monitoring system [EMS] compns1ng of energy meter with LAN interface which can be connected with existing LAN network to collect the data instantaneously and store it in the database server. The energy meter inputs are taken from three current sensors to measure line current and three lines are connected to the energy meter to measure the line voltages. The web application manipulates the data and produce current data and manipulated data in the form of reports.

  • Rugged construction
  • Precisely designed
  • Rust proof
